11.2.3 Function block
GUID-94B75A6D-973D-4F1F-8643-F2128AD31CC4 v3
SSIMG
BLOCK
BLKALM
SENPRES
SENTEMP
SENPRESALM
SENPRESLO
SETPLO
SETTLO
RESETLO
LOCKOUT
PRESLO
TEMPLO
ALARM
PRESALM
TEMPALM
PRESSURE
TEMP
IEC09000129-2-en.vsdx
IEC09000129 V2 EN-US
Figure 204: SSIMG function block
11.2.4 Signals
GUID-89749F71-CAEB-4A57-A1F0-148CCF68E97E v2
PID-6950-INPUTSIGNALS v6
Table 326: SSIMG Input signals
Name Type Default Description
BLOCK BOOLEAN 0 Block of function
BLKALM BOOLEAN 0 Block all the alarms
SENPRES REAL 0.0 Pressure input from CB
SENTEMP REAL 0.0 Temperature of the insulation medium from CB
SENPRESALM BOOLEAN 0 Pressure alarm signal
SENPRESLO BOOLEAN 0 Pressure lockout signal
SETPLO BOOLEAN 0 Set pressure lockout
SETTLO BOOLEAN 0 Set temperature lockout
RESETLO BOOLEAN 0 Reset pressure and temperature lockout
PID-6950-OUTPUTSIGNALS v6
Table 327: SSIMG Output signals
Name
Type Description
LOCKOUT BOOLEAN Pressure below lockout level or temperature
above lockout level
PRESLO BOOLEAN Pressure below lockout level
TEMPLO BOOLEAN Temperature above lockout level
ALARM BOOLEAN Pressure below alarm level or temperature above
alarm level
PRESALM BOOLEAN Pressure below alarm level
TEMPALM BOOLEAN Temperature above alarm level
PRESSURE REAL Pressure service value
TEMP REAL Temperature of the insulation medium
1MRK 505 384-UEN A Section 11
Monitoring
Breaker protection REQ650 2.2 IEC 427
Technical manual
