Name Type Default Description
INPUT13 GROUP
SIGNAL
0 Input 13
INPUT14 GROUP
SIGNAL
0 Input 14
INPUT15 GROUP
SIGNAL
0 Input 15
INPUT16 GROUP
SIGNAL
0 Input 16
11.5.5 Settings
IP11336-1 v2
PID-4145-SETTINGS v6
Table 343: EVENT Non group settings (basic)
Name Values (Range) Unit Step Default Description
SPAChannelMask Off
Channel 1-8
Channel 9-16
Channel 1-16
-
- Off SPA channel mask
LONChannelMask Off
Channel 1-8
Channel 9-16
Channel 1-16
-
- Off LON channel mask
EventMask1 NoEvents
OnSet
OnReset
OnChange
AutoDetect
-
- AutoDetect Reporting criteria for input 1
EventMask2 NoEvents
OnSet
OnReset
OnChange
AutoDetect
-
- AutoDetect Reporting criteria for input 2
EventMask3 NoEvents
OnSet
OnReset
OnChange
AutoDetect
-
- AutoDetect Reporting criteria for input 3
EventMask4 NoEvents
OnSet
OnReset
OnChange
AutoDetect
-
- AutoDetect Reporting criteria for input 4
EventMask5 NoEvents
OnSet
OnReset
OnChange
AutoDetect
-
- AutoDetect Reporting criteria for input 5
EventMask6 NoEvents
OnSet
OnReset
OnChange
AutoDetect
-
- AutoDetect Reporting criteria for input 6
Table continues on next page
