Section 2 Available functions
GUID-F5776DD1-BD04-4872-BB89-A0412B4B5CC3 v1
The following tables list all the functions available in the IED.
Those functions that are not exposed to the user or do not need to
be configured are not described in this manual.
2.1 Back-up protection functions
GUID-A8D0852F-807F-4442-8730-E44808E194F0 v13
IEC 61850 or
function name
ANSI Function description Breaker
REQ650 (B11)
Current protection
PHPIOC 50 Instantaneous phase overcurrent protection 1
OC4PTOC
51_67
1)
Directional phase overcurrent protection, four steps 1
EFPIOC 50N Instantaneous residual overcurrent protection 1
EF4PTOC 51N
67N
2)
Directional residual overcurrent protection, four steps 1
NS4PTOC 46I2 Four step directional negative phase sequence overcurrent protection 1
LCPTTR 26 Thermal overload protection, one time constant, Celsius 1
LFPTTR 26 Thermal overload protection, one time constant, Fahrenheit 1
CCRBRF 50BF Breaker failure protection 1
STBPTOC 50STB Stub protection 1
CCPDSC 52PD Pole discordance protection 1
BRCPTOC 46 Broken conductor check 1
Voltage protection
UV2PTUV 27 Two step undervoltage protection 1
OV2PTOV 59 Two step overvoltage protection 1
ROV2PTOV 59N Two step residual overvoltage protection 1
LOVPTUV 27 Loss of voltage check 1
1) 67 requires voltage
2) 67N requires voltage
1MRK 505 384-UEN A Section 2
Available functions
Breaker protection REQ650 2.2 IEC 37
Technical manual
