Function Range or value Accuracy
Maximum voltage for
energizing
(50.0-180.0)% of UBase ±0.5% of U
r
at U ≤ U
r
±0.5% of U at U > U
r
Time delay for energizing
check when voltage jumps
from 0 to 90% of Urated
(0.000-60.000) s
±0.2% or ±100 ms whichever is
greater
Operate time for
synchrocheck function when
angle difference between
bus and line jumps from
“PhaseDiff” + 2 degrees to
“PhaseDiff” - 2 degrees
Min. = 15 ms
Max. = 30 ms
–
Operate time for energizing
function when voltage jumps
from 0 to 90% of Urated
Min. = 70 ms
Max. = 90 ms
–
9.2 Autorecloser for 1 phase, 2 phase and/or 3 phase
operation SMBRREC
IP14559-1 v6
9.2.1 Identification
M14890-1 v7
Function Description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Autorecloser for 1 phase, 2 phase and/or 3
phase
SMBRREC
IEC15000204 V1 EN-US
79
9.2.2 Functionality
M12390-3 v16
The auto reclosing function provides:
• high-speed and/or delayed auto reclosing
• single and/or three phase auto reclosing
• support for single or multi-breaker applications.
The auto recloser can be used for delayed busbar restoration.
Up to five reclosing shots can be performed. The first shot can be single-, two-,
and /or three-phase depending on the type of the fault and the selected auto
reclosing mode.
Several auto reclosing functions can be provided for multi-breaker arrangements. A
priority circuit allows one circuit breaker to reclose first and the second will only
close if the fault proved to be transient.
1MRK 505 384-UEN A Section 9
Control
Breaker protection REQ650 2.2 IEC 241
Technical manual
