Table 301: VNMMXU Output signals
Name Type Description
UL1 REAL UL1 Amplitude, magnitude of reported value
UL1RANG INTEGER UL1 Amplitude range
UL1ANGL REAL UL1 Angle, magnitude of reported value
UL2 REAL UL2 Amplitude, magnitude of reported value
UL2RANG INTEGER UL2 Amplitude range
UL2ANGL REAL UL2 Angle, magnitude of reported value
UL3 REAL UL3 Amplitude, magnitude of reported value
UL3RANG INTEGER UL3 Amplitude range
UL3ANGL REAL UL3 Angle, magnitude of reported value
11.1.5 Settings
SEMOD130322-4 v7
The available setting parameters of the measurement function (MMXU, MSQI) are
depending on the actual hardware (TRM) and the logic configuration made in
PCM600.
These six functions are not handled as a group, so parameter settings are only
available in the first setting group.
The following terms are used in the Unit and Description columns:
• UBase (UB): Base voltage in primary kV. This voltage is used as reference for
voltage setting. It can be suitable to set this parameter to the rated primary
voltage supervised object.
• IBase (IB): Base current in primary A. This current is used as reference for
current setting. It can be suitable to set this parameter to the rated primary
current of the supervised object.
• SBase (SB): Base setting for power values in MVA.
PID-6713-SETTINGS v3
Table 302: CVMMXN Non group settings (basic)
Name
Values (Range) Unit Step Default Description
SLowLim 0.0 - 2000.0 %SB 0.1 80.0 Low limit in % of SBase
SLowLowLim 0.0 - 2000.0 %SB 0.1 60.0 Low Low limit in % of SBase
SMin 0.0 - 2000.0 %SB 0.1 50.0 Minimum value in % of SBase
SMax 0.0 - 2000.0 %SB 0.1 200.0 Maximum value in % of SBase
SRepTyp Cyclic
Deadband
Int deadband
Db & Cyclic 5s
Db & Cyclic 30s
Db & Cyclic 1min
-
- Cyclic Reporting type
Table continues on next page
Section 11 1MRK 505 384-UEN A
Monitoring
398 Breaker protection REQ650 2.2 IEC
Technical manual
