10.5 Logic for group warning WRNCALH
10.5.1 Identification
GUID-3EBD3D5B-F506-4557-88D7-DFC0BD21C690 v4
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Logic for group warning WRNCALH - -
10.5.2 Functionality
GUID-F7D9A012-3AD4-4D86-BE97-DF2A99BE5383 v4
The group warning logic function (WRNCALH) is used to route several warning
signals to a common indication, LED and/or contact, in the IED.
10.5.3 Function block
GUID-C909E4FB-3F7A-47F7-8988-36B159E2C7B2 v1
WRNCALH
BLOCK
INPUT1
INPUT2
INPUT3
INPUT4
INPUT5
INPUT6
INPUT7
INPUT8
INPUT9
INPUT10
INPUT11
INPUT12
INPUT13
INPUT14
INPUT15
INPUT16
WARNING
IEC13000182-1-en.vsd
IEC13000182 V1 EN-US
10.5.4 Signals
PID-4127-INPUTSIGNALS v3
Table 214: WRNCALH Input signals
Name
Type Default Description
BLOCK BOOLEAN 0 Block of function
INPUT1 BOOLEAN 0 Binary input 1
INPUT2 BOOLEAN 0 Binary input 2
INPUT3 BOOLEAN 0 Binary input 3
INPUT4 BOOLEAN 0 Binary input 4
INPUT5 BOOLEAN 0 Binary input 5
INPUT6 BOOLEAN 0 Binary input 6
INPUT7 BOOLEAN 0 Binary input 7
INPUT8 BOOLEAN 0 Binary input 8
Table continues on next page
1MRK 505 384-UEN A Section 10
Logic
Breaker protection REQ650 2.2 IEC 349
Technical manual
