Name Values (Range) Unit Step Default Description
DNP3 Off
On
- - On DNP3 slave
SNTPServer Off
On
- - On SNTP Server
FSTAccess Off
On
- - On Field Service Tool access
C37.118TCP Off
On
- - On IEEE 1344 and C37.118 TCP server
C37.118UDP1 Off
On
- - On IEEE 1344 and C37.118 UDP stream
and the TCP control server
C37.118UDP2 Off
On
- - On IEEE 1344 and C37.118 UDP stream
and the TCP control server
C37.118UDP3 Off
On
- - On IEEE 1344 and C37.118 UDP stream
and the TCP control server
C37.118UDP4 Off
On
- - On IEEE 1344 and C37.118 UDP stream
and the TCP control server
C37.118UDP5 Off
On
- - On IEEE 1344 and C37.118 UDP stream
and the TCP control server
C37.118UDP6 Off
On
- - On IEEE 1344 and C37.118 UDP stream
and the TCP control server
DefaultGateway 0 - 18 IP
Address
1 0.0.0.0 Default gateway IP address
PID-6811-SETTINGS v3
Table 383: DHCP Non group settings (basic)
Name
Values (Range) Unit Step Default Description
DHCPServer Off
On
- - Off Access point front DHCP server
operation
13.2 Access point diagnostics
13.2.1 Functionality
GUID-20F64A6D-AA8C-47D7-AA7D-4810996B2FF2 v1
The access point diagnostics function blocks (RCHLCCH, SCHLCCH and
FRONTSTATUS) supervise communication. SCHLCCH is used for
communication over the rear Ethernet ports, RCHLCCH is used for redundant
communications over the rear Ethernet ports and FRONTSTATUS is used for
communication over the front port. All access point function blocks include output
signal for denial of service.
1MRK 505 384-UEN A Section 13
Ethernet
Breaker protection REQ650 2.2 IEC 509
Technical manual
