14.4.4 Technical data
IP14434-1 v1
M15031-1 v8
Table 397: Communication protocols
Function
Value
Protocol IEC 61850-8-1
Communication speed for the IEDs 100BASE-FX
Protocol IEC 60870–5–103
Communication speed for the IEDs 9600 or 19200 Bd
Protocol DNP3.0
Communication speed for the IEDs 300–115200 Bd
Protocol TCP/IP, Ethernet
Communication speed for the IEDs 100 Mbit/s
Protocol LON
Communication speed for the IEDs 1.25 Mbit/s
Protocol SPA
Communication speed for the IEDs 300–38400 Bd
14.4.5 Generic communication function for Single Point indication
SPGAPC, SP16GAPC
SEMOD55999-1 v4
14.4.5.1 Function block
SEMOD54714-4 v4
SPGAPC
BLOCK
^IN
IEC14000021-1-en.vsd
IEC14000021 V1 EN-US
Figure 252: SPGAPC function block
SP16GAPC
BLOCK
^IN1
^IN2
^IN3
^IN4
^IN5
^IN6
^IN7
^IN8
^IN9
^IN10
^IN11
^IN12
^IN13
^IN14
^IN15
^IN16
IEC14000020-1-en.vsd
IEC14000020 V1 EN-US
Figure 253: SP16GAPC function block
Section 14 1MRK 505 384-UEN A
Station communication
526 Breaker protection REQ650 2.2 IEC
Technical manual
