14.7 SPA communication protocol
IP14614-1 v1
14.7.1 Functionality
M11897-3 v6
In this section the most common addresses for commands and events are available.
For other addresses, refer to section Related documents.
It is assumed that the reader is familiar with the SPA communication protocol in
general.
14.7.2 Design
M11877-3 v6
Using the rear SPA port for either local or remote communication with a PC
requires the following equipment:
• Optical fibres
• Opto/electrical converter for the PC
• PC
SPA cannot be accessed via PCM600.
When communicating between the local HMI and a PC, the only hardware required
is a front-connection cable.
SPA can be accessed via LHMI front only when using the Field
Service Tool Access (FSTACCS).
14.7.3 Settings
IP14403-1 v2
PID-6195-SETTINGS v5
Table 430: SPA Non group settings (basic)
Name
Values (Range) Unit Step Default Description
SlaveAddress 1 - 899 - 1 30 Slave address
BaudRate 300 Bd
1200 Bd
2400 Bd
4800 Bd
9600 Bd
19200 Bd
38400 Bd
-
- 9600 Bd Baudrate on serial line
1MRK 505 384-UEN A Section 14
Station communication
Breaker protection REQ650 2.2 IEC 579
Technical manual
