EVENT
BLOCK
^INPUT1
^INPUT2
^INPUT3
^INPUT4
^INPUT5
^INPUT6
^INPUT7
^INPUT8
^INPUT9
^INPUT10
^INPUT11
^INPUT12
^INPUT13
^INPUT14
^INPUT15
^INPUT16
Block
ILRANG
PSTO
UL12RANG
UL31RANG
UL23RANG
3I0RANG
3U0RANG
FALSE
IEC07000065-2-en.vsd
IEC07000065 V2 EN-US
Figure 269: Connection of protection signals for event handling
14.7.4.1 Communication ports
M11880-315 v6
The serial communication module (SLM) is a mezzanine module placed on the first
analog digital conversion module (ADM). It is used for LON, SPA, IEC
60870-5-103 and DNP communication.
In the following figure, X311 ports A/B are for SPA, IEC103 or DNP3 and X311
ports C/D are for LON protocol.
1MRK 505 384-UEN A Section 14
Station communication
Breaker protection REQ650 2.2 IEC 585
Technical manual
