14.8.3.4 Signals
PID-3791-INPUTSIGNALS v5
Table 438: I103MEASUSR Input signals
Name
Type Default Description
BLOCK BOOLEAN 0 Block of service value reporting
INPUT1 REAL 0.0 Service value for measurement on input 1
INPUT2 REAL 0.0 Service value for measurement on input 2
INPUT3 REAL 0.0 Service value for measurement on input 3
INPUT4 REAL 0.0 Service value for measurement on input 4
INPUT5 REAL 0.0 Service value for measurement on input 5
INPUT6 REAL 0.0 Service value for measurement on input 6
INPUT7 REAL 0.0 Service value for measurement on input 7
INPUT8 REAL 0.0 Service value for measurement on input 8
INPUT9 REAL 0.0 Service value for measurement on input 9
14.8.3.5 Settings
PID-3791-SETTINGS v5
Table 439: I103MEASUSR Non group settings (basic)
Name
Values (Range) Unit Step Default Description
FunctionType 1 - 255 - 1 25 Function type (1-255)
InfNo 1 - 255 - 1 1 Information number for measurands
(1-255)
MaxMeasur1 0.05 -
10000000000.00
- 0.05 1000.00 Maximum value for measurement on
input 1
MaxMeasur2 0.05 -
10000000000.00
- 0.05 1000.00 Maximum value for measurement on
input 2
MaxMeasur3 0.05 -
10000000000.00
- 0.05 1000.00 Maximum value for measurement on
input 3
MaxMeasur4 0.05 -
10000000000.00
- 0.05 1000.00 Maximum value for measurement on
input 4
MaxMeasur5 0.05 -
10000000000.00
- 0.05 1000.00 Maximum value for measurement on
input 5
MaxMeasur6 0.05 -
10000000000.00
- 0.05 1000.00 Maximum value for measurement on
input 6
MaxMeasur7 0.05 -
10000000000.00
- 0.05 1000.00 Maximum value for measurement on
input 7
MaxMeasur8 0.05 -
10000000000.00
- 0.05 1000.00 Maximum value for measurement on
input 8
MaxMeasur9 0.05 -
10000000000.00
- 0.05 1000.00 Maximum value for measurement on
input 9
Section 14 1MRK 505 384-UEN A
Station communication
590 Breaker protection REQ650 2.2 IEC
Technical manual
