14.8.10.4 Signals
PID-3969-INPUTSIGNALS v5
Table 452: I103CMD Input signals
Name
Type Default Description
BLOCK BOOLEAN 0 Block of commands
PID-3969-OUTPUTSIGNALS v5
Table 453: I103CMD Output signals
Name Type Description
16-AR BOOLEAN Information number 16, off/on of autorecloser
17-DIFF BOOLEAN Information number 17, block of differential
protection
18-PROT BOOLEAN Information number 18, block of protection
14.8.10.5 Settings
PID-3969-SETTINGS v5
Table 454: I103CMD Non group settings (basic)
Name
Values (Range) Unit Step Default Description
FunctionType 1 - 255 - 1 1 Function type (1-255)
14.8.11 IED commands for IEC 60870-5-103 I103IEDCMD
14.8.11.1 Functionality
GUID-19AD44B2-21D6-4DB0-AD74-1578DA30C100 v5
I103IEDCMD is a command block in control direction with defined IED functions.
All outputs are pulsed and they are NOT stored. Pulse length is fixed to 400ms.
14.8.11.2 Identification
GUID-0D0B2477-1B0C-48F3-B047-CCF9C7A71856 v1
Function description
Function block
name
IEC 60617
identification
ANSI/IEEE C37.2
device number
IED commands for IEC 60870-5-103 I103IEDCMD - -
Section 14 1MRK 505 384-UEN A
Station communication
602 Breaker protection REQ650 2.2 IEC
Technical manual
