Information number is defined for each output signals.
Table 469: Pre-defined I103CMD supported indications
INF
Description
16 Auto-recloser on/off
17 Teleprotection on/off
18 Protection on/off
Function commands in control direction, user-defined, I103USRCMD
M11874-72 v6
Function command blocks in control direction with user-defined output signals.
Number of instances: 4
Function type for each function block instance in private range is selected with
parameter FunctionType.
Information number must be selected for each output signal. Default values are 1 -
8.
Table 470: I103USRCMD supported indications
INF
1)
Description
1 Output signal 01
2 Output signal 02
3 Output signal 03
4 Output signal 04
5 Output signal 05
6 Output signal 06
7 Output signal 07
8 Output signal 08
1) User defined information number
Status
M11874-107 v1
Terminal status indications in monitor direction, I103IED
M11874-109 v7
Indication block for status in monitor direction with defined IED functions.
Number of instances: 1
Function type is selected with parameter FunctionType.
Information number is defined for each input signals.
1MRK 505 384-UEN A Section 14
Station communication
Breaker protection REQ650 2.2 IEC 611
Technical manual
