Section 5 Local Human-Machine-Interface LHMI
5.1 Local HMI screen behaviour
5.1.1 Identification
GUID-84392EFF-4D3F-4A67-A6ED-34C6E98574D6 v1
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Local HMI screen behaviour SCREEN - -
5.2 Local HMI signals
5.2.1 Identification
GUID-03AB7AEE-87D3-4F3C-B6B9-B1EB1B538E38 v1
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Local HMI signals LHMICTRL - -
5.2.2 Function block
GUID-A8AC51E9-5BD7-4A80-9576-4816F14DD08D v2
LHMICTRL
CLRLEDS HMI-ON
RED-S
YELLOW-S
YELLOW-F
CLRPULSE
LEDSCLRD
IEC09000320-1-en.vsd
IEC09000320 V1 EN-US
Figure 3: LHMICTRL function block
5.2.3 Signals
PID-3992-INPUTSIGNALS v6
Table 20: LHMICTRL Input signals
Name
Type Default Description
CLRLEDS BOOLEAN 0 Input to clear the LCD-HMI LEDs
1MRK 505 384-UEN A Section 5
Local Human-Machine-Interface LHMI
Breaker protection REQ650 2.2 IEC 57
Technical manual
