firmware versions depending on the small issues corrected in between
releases.
• ProductVer
• Describes the product version. Example: 2.1.0
1
is the Major version of the manufactured product this means, new platform of the
product
2 is the Minor version of the manufactured product this means, new functions or new
hardware added to the product
3 is the Major revision of the manufactured product this means, functions or hardware
is either changed or enhanced in the product
• IEDMainFunType
• Main function type code according to IEC 60870-5-103. Example: 128
(meaning line protection).
• SerialNo
• OrderingNo
• ProductionDate
16.6 Signal matrix for binary inputs SMBI
SEMOD55793-1 v2
16.6.1 Functionality
M15302-3 v5
The Signal matrix for binary inputs (SMBI) function is used within the Application
Configuration Tool (ACT) in direct relation with the Signal Matrix Tool (SMT),
see the application manual to get information about how binary inputs are brought
in for one IED configuration.
16.6.2 Function block
M15306-3 v3
IEC05000434-2-en.vsd
SMBI
^VIN1
^VIN2
^VIN3
^VIN4
^VIN5
^VIN6
^VIN7
^VIN8
^VIN9
^VIN10
^BI1
^BI2
^BI3
^BI4
^BI5
^BI6
^BI7
^BI8
^BI9
^BI10
IEC05000434 V2 EN-US
Figure 298: SMBI function block
Section 16 1MRK 505 384-UEN A
Basic IED functions
664 Breaker protection REQ650 2.2 IEC
Technical manual
