17.2.5.2 Design
M14858-3 v7
The rated values and channel type of the current inputs are selected at order.
Transformer input module for measuring should not be used with
current transformers intended for protection purposes, due to
limitations in overload characteristics.
The TRM is connected to the ADM and NUM.
For configuration of the input and output signals, refer to section
"Signal matrix for
analog inputs SMAI".
1MRK006501-AF-TRM-IEC-6502P1 V1 EN-US
Figure 306: TRM connection diagram
1MRK 505 384-UEN A Section 17
IED hardware
Breaker protection REQ650 2.2 IEC 683
Technical manual
