17.2.8.4 Settings
PID-3439-SETTINGS v2
Table 553: BOM Non group settings (basic)
Name
Values (Range) Unit Step Default Description
Operation Off
On
- - On Operation Off/On
17.2.8.5 Monitored data
PID-3439-MONITOREDDATA v2
Table 554: BOM Monitored data
Name Type Values (Range) Unit Description
STATUS BOOLEAN 0=Ok
1=Error
- Binary output part of
IOM module status
BO1VALUE BOOLEAN 1=1
0=0
- Binary output 1 value
BO1FORCE BOOLEAN 0=Normal
1=Forced
- Binary output 1 force
BO1 BOOLEAN 0=Normal
1=Forced
2=Blocked
-
Binary output 1 status
BO2VALUE BOOLEAN 1=1
0=0
- Binary output 2 value
BO2FORCE BOOLEAN 0=Normal
1=Forced
- Binary output 2 force
BO2 BOOLEAN 0=Normal
1=Forced
2=Blocked
-
Binary output 2 status
BO3VALUE BOOLEAN 1=1
0=0
- Binary output 3 value
BO3FORCE BOOLEAN 0=Normal
1=Forced
- Binary output 3 force
BO3 BOOLEAN 0=Normal
1=Forced
2=Blocked
-
Binary output 3 status
BO4VALUE BOOLEAN 1=1
0=0
- Binary output 4 value
BO4FORCE BOOLEAN 0=Normal
1=Forced
- Binary output 4 force
BO4 BOOLEAN 0=Normal
1=Forced
2=Blocked
-
Binary output 4 status
BO5VALUE BOOLEAN 1=1
0=0
- Binary output 5 value
BO5FORCE BOOLEAN 0=Normal
1=Forced
- Binary output 5 force
BO5 BOOLEAN 0=Normal
1=Forced
2=Blocked
-
Binary output 5 status
Table continues on next page
