Name Type Default Description
BO3 BOOLEAN 0 Binary output 3
BO4 BOOLEAN 0 Binary output 4
BO5 BOOLEAN 0 Binary output 5
BO6 BOOLEAN 0 Binary output 6
BO7 BOOLEAN 0 Binary output 7
BO8 BOOLEAN 0 Binary output 8
BO9 BOOLEAN 0 Binary output 9
BO10 BOOLEAN 0 Binary output 10
BO11 BOOLEAN 0 Binary output 11
BO12 BOOLEAN 0 Binary output 12
17.2.9.4 Settings
PID-4050-SETTINGS v2
Table 558: IOMIN Non group settings (basic)
Name Values (Range) Unit Step Default Description
Operation Off
On
- - On Binary input/output module in operation
(On) or not (Off)
DebounceTime 0.001 - 0.020 s 0.001 0.001 Debounce time for binary inputs
OscBlock 1 - 40 Hz 1 40 Oscillation block limit
OscRelease 1 - 30 Hz 1 30 Oscillation release limit
17.2.9.5 Monitored data
PID-4050-MONITOREDDATA v2
Table 559: IOMIN Monitored data
Name
Type Values (Range) Unit Description
STATUS BOOLEAN 0=Ok
1=Error
- Binary input part of IOM
module status
PID-4049-MONITOREDDATA v2
Table 560: IOMOUT Monitored data
Name
Type Values (Range) Unit Description
BO1VALUE BOOLEAN 1=1
0=0
- Binary output 1 value
BO1FORCE BOOLEAN 0=Normal
1=Forced
- Binary output 1 force
BO1 BOOLEAN 0=Normal
1=Forced
2=Blocked
-
Binary output 1 status
BO2VALUE BOOLEAN 1=1
0=0
- Binary output 2 value
Table continues on next page
1MRK 505 384-UEN A Section 17
IED hardware
Breaker protection REQ650 2.2 IEC 701
Technical manual
