Name Type Values (Range) Unit Description
BO9 BOOLEAN 0=Normal
1=Forced
2=Blocked
-
Binary output 9 status
BO10VALUE BOOLEAN 1=1
0=0
- Binary output 10 value
BO10FORCE BOOLEAN 0=Normal
1=Forced
- Binary output 10 force
BO10 BOOLEAN 0=Normal
1=Forced
2=Blocked
-
Binary output 10 status
BO11VALUE BOOLEAN 1=1
0=0
- Binary output 11 value
BO11FORCE BOOLEAN 0=Normal
1=Forced
- Binary output 11 force
BO11 BOOLEAN 0=Normal
1=Forced
2=Blocked
-
Binary output 11 status
BO12VALUE BOOLEAN 1=1
0=0
- Binary output 12 value
BO12FORCE BOOLEAN 0=Normal
1=Forced
- Binary output 12 force
BO12 BOOLEAN 0=Normal
1=Forced
2=Blocked
-
Binary output 12 status
17.2.9.6 Technical data
IP10636-1 v1
M12573-1 v9
Table 561: IOM - Binary input/output module
Quantity
Rated value Nominal range
Binary inputs 8 -
DC voltage, RL 24/30 V
48/60 V
110/125 V
220/250 V
RL ±20%
RL ±20%
RL ±20%
RL ±20%
Power consumption
24/30 V, 50 mA
48/60 V, 50 mA
110/125 V, 50 mA
220/250 V, 50 mA
220/250 V, 110 mA
max. 0.05 W/input
max. 0.1 W/input
max. 0.2 W/input
max. 0.4 W/input
max. 0.5 W/input
-
Counter input frequency 10 pulses/s max
Oscillating signal discriminator Blocking settable 1-40 Hz
Release settable 1-30 Hz
Debounce filter Settable 1-20 ms
1MRK 505 384-UEN A Section 17
IED hardware
Breaker protection REQ650 2.2 IEC 703
Technical manual
