M12327-1 v4
Table 571: Water and dust protection level according to IEC 60529
Front IP40 (IP54 with sealing strip)
Sides, top and bottom IP40
Rear side IP20 with screw compression type
IP10 with ring lug terminals
M11777-1 v5
Table 572: Weight
Case size Weight
6U, 1/2 x 19”
£ 10 kg/22 lb
17.5.2 Electrical safety
GUID-2825B541-DD31-4DAF-B5B3-97555F81A1C2 v1
GUID-1CF5B10A-CF8B-407D-8D87-F4B48B43C2B2 v1
Table 573: Electrical safety according to IEC 60255-27
Equipment class I (protective earthed)
Overvoltage category III
Pollution degree 2 (normally only non-conductive pollution occurs except that occasionally
a temporary conductivity caused by condensation is to be expected)
17.5.3 Connection system
SEMOD53371-1 v1
SEMOD53376-2 v6
Table 574: CT and VT circuit connectors
Connector type
Rated voltage and current Maximum conductor area
Screw compression type 250 V AC, 20 A
4 mm
2
(AWG12)
2 x 2.5 mm
2
(2 x AWG14)
Terminal blocks suitable for
ring lug terminals
250 V AC, 20 A
4 mm
2
(AWG12)
M12583-1 v6
Table 575: Auxiliary power supply connectors
Connector type
Rated voltage Maximum conductor area
Screw compression type 250 V AC
2.5 mm
2
(AWG14)
2 × 1 mm
2
(2 x AWG18)
Terminal blocks suitable for
ring lug terminals
300 V AC
3 mm
2
(AWG14)
1MRK 505 384-UEN A Section 17
IED hardware
Breaker protection REQ650 2.2 IEC 725
Technical manual
