SummaCut cutter User’s Manual
Setup 1-6
5. Tool carriage: The tool carriage is the mount for the knife holder, pen or pouncing
tool. It has also holds the Optical POSitioning sensor (OPOS).
6. Cutting strip: A self-healing orange strip helps avoid any damage to the knife tip
when no media has been loaded. Since cutting is done on the cutting strip, it is
essential that the strip remains intact.
7. Media sensor: A media sensor behind the right sleeve is used to detect the end of
the loaded media.
8. Media guide: Only on smaller models, prevents the media slipping under the
cutter when installed on a table.
9. Screws to secure the cutter base: Make sure all screws are secured at each
side before the cutter is used.
10. Media basket: The stand and linen media basket come standard with all D120,
D140 and D160 models.
