SummaCut cutter User’s Manual
Contour Cutting 3-12
3.3.6 Registering the markers
Most cutting software will initiate the special load procedure after the parameters are
sent. If the software does not do this, then initiate the loading sequence from the
cutter’s touch panel.
Registering the markers:
1. Power on the cutter and load the media.
2. Press
.
‘Velocity’ will appear on the LCD.
3. Use
or to scroll through the menu until ‘Align Load’ is reached, then
press
.
A message prompting the user to set the knife above the first marker will scroll
across the LCD.
4. Use
, , and to do so and press .
The cutter will reload the media to check if the loaded length matches with the
OPOS parameters used. Then it will return and read the markers.
NOTE: If a marker cannot be read, then the user will be given the option to re-
position the knife (sensor) or to abort.
NOTE: If an error occurs or the cutter cannot read the markers after three
attempts, the following message will be displayed: ”Markers could not be sensed,
press to continue.”
