Summa SummaCut D120 - 6.3 Technical Specification

SummaCut cutter User’s Manual
Specifications 6-3
6.3 Technical Specification
6.3.1 Machine dimensions
D60(SE) D120(SE) D140SE D160SE
mm inch mm inch mm inch mm inch
Height 300 11.8 1120 44.1 1145 45.1 1145 45.1
Width 1000 39.4 1600 63.0 1750 68.9 1980 77.9
Depth 350 13.8 680 26.8 680 26.8 680 26.8
Weight 15 kg 33 lbs 42 kg 92 lbs 48 kg 106 lbs 54 kg 119 lbs
TABLE 2:
MACHINE DIMENSIONS
6.3.2 shipping dimensions
D60(SE) D120(SE) D140SE D160SE
mm inch mm inch mm inch mm inch
Height 470 18.5 670 26.4 670 26.4 670 26.4
Width 1130 51.2 1740 68.5 1880 74.0 2110 83.1
Depth 470 18.5 470 18.5 470 18.5 470 18.5
Weight 23 kg 51 lbs 57 kg 125 lbs 69 kg 152 lbs 78 kg 172 lbs
TABLE 3:
SHIPPING DIMENSIONS
