SummaCut cutter User’s Manual
Detailed Operation 4-12
4.3.23 Calibrate X/Y
Length calibration allows the length of the lines cut to be adjusted to within the
specifications.
For instance, if a cut line should measure 100 mm exactly, the cutter can be adjusted
for any discrepancy.
Calibration is explained in section
2.5.
4.3.24 Coil Setup
This test is used to calibrate knife and pen pressure and to set the knife and pen
“landing.”
The cut quality is seriously affected by incorrect landing settings. Before changing
these values, write them down, as there is no default setting for these parameters.
After adjustment, the value is saved in the system’s non-volatile RAM.
Press the button, then use
or to switch between the parameters and
use
or to change the value of the current chosen parameter.
Press
to confirm or to cancel.
Setting 40g pressure and 400g pressure.
To execute this test, a tension gauge of ± 100 gr and ± 600 gr is required.
Measure the pressure on the knife with the tension gauge (read value from the gauge
when knife just lifts from the media.) Use
or to change the value of the
parameter so that the readout on the tension gauge matches the value on the LCDen
(40g or 400g depending on the parameter that is calibrated).
Setting the landing
The landing determines, among other things, the force at which the tool hits the
media. When calibrating the landing, the tool holder with the knife must be inserted in
the head. Be sure that the knife does not protrude.
Use
to lower the landing value until the tool is in the “up” position. Then use to
raise the value of the parameter. With each unit of change, continue checking if the
tool is completely down yet. Once the tool is completely down, raise the value back up
two units, and this becomes the proper setting.
4.3.25 Cal. Media
Media calibration ensures that the sensor is able to recognize the markers. This is
explained in section
3.2.2
