SummaCut cutter User’s Manual
Basic Operation 2-2
2.1.1 Control Panel
2.1.1.1 The menu key
The MENU key is used to reach the most common menu items of the cutter quickly. A
last menu item in the row gives access to a submenu with which all the other functions
of the cutter can be reached (see section 2.3).
2.1.1.2 The exit key
The EXIT key (cancel key) cancels the current operation
Pressing this key when the cutter is cutting stops the current job.
2.1.1.3 The enter key
The ENTER Key (confirm key) confirms a selected menu or a changed menu item.
As long as this key is not pressed a changed value of a menu item is not saved
internally and can will be lost if the menu is left.
2.1.1.4 The test key
If there is a certain test routine in a submenu, then it can be activated to start it.
The test key can also be used to set the cutter offline during a job and check the result
with the jogging keys. Press the
key to go online again.
2.1.1.5 The jogging keys
, , and
The use of the jogging keys varies according to the operation in progress.
For example, when working with different submenus, the
or jogging key is
used to select the next or previous submenu.
When in a submenu the values can be changed by pressing
or .
When the cutter is normal operation, then by pressing either one of the jogging keys,
the origin can be changed.
