SummaCut cutter User’s Manual
Contour Cutting 3-4
3. Press to confirm.
The cutter will make a circular movement while it measures the reflection of the
media. It will briefly display the measured values and display the message “put
sensor on black area.”
4. Use
, , and to maneuver the knife on top of a black area
(approximately in the middle and slightly to the bottom right).
5. Press to confirm.
The cutter will make a circular movement while it measures the reflection of the
marker color. It will briefly display the measured values, then it will show a value
that is characteristic for this media color – marker color combination. Store this
value for future reference.
NOTE: An error message may appear if the sensor is not able to differentiate
between black and white. Make sure that the test has been performed correctly. If
OPOS is not able to sense the markers, one of the manual alignment methods (see
Error! Reference source not found..) must be used.
