Chapter 1 Preparing to Service the System 39
2. Connect the terminal’s power cable to an AC outlet.
3. Set the terminal to receive:
■ At 9600 baud
■ An 8-bit signal with no parity and 1 stop bit
See the documentation accompanying your terminal for more information.
What Next
You can now issue system commands from the terminal keyboard and view system
messages. Continue with your installation or diagnostic procedure as needed.
How to Configure a Local Graphics
Console
Before You Begin
If your server is configured without an alphanumeric (ASCII) terminal, you need to
install a local graphics console in order to install the system and to run diagnostic
tests. For background information, see “About Communicating With the System” on
page 37.
To install a local graphics console, you must have:
■ A supported PCI-based graphics frame buffer card and software driver
■ An 8-bit Color Graphics PCI Adapter Frame buffer card—Sun part number
X3660A is currently supported
■ A 32 8/24-bit Color Graphics PCI Adapter Frame buffer card—Sun part
number X3668A is currently supported
■ A monitor with appropriate resolution
■ A Sun-compatible USB keyboard (Sun USB Type 6 keyboard)
■ A Sun-compatible USB mouse (Sun USB mouse) and mouse pad (if necessary)
Alternatively, you can attach an alphanumeric (ASCII) terminal to the system’s serial
port or create a tip connection from another Sun system. See “About
Communicating With the System” on page 37 for more information.
