Sun Microsystems SUN FIRE 280R - Page 79

Chapter 2 Servicing the Main Logic Board and Components 53
8. Using a Phillips No. 2 screwdriver, remove the screw that secures the card to the
chassis back panel.
9. Pull the RSC card from its slot.
Caution – Do not apply excessive force to one end or one side of the board. Doing
so could damage the card.
