20 Sun Fire T1000 Server Installation Guide • January 2006
▼ To Install the Cable Management Bracket
1. Place the cable management bracket across the slide rail assemblies behind the
system chassis.
2. Press down on each end of the cable management bracket until the ends click into
place on the mounting brackets.
3. When you attach cables to the server, as in the following procedures, lay the
cables over the cable management bracket, then use cable ties to hold each cable
in place.
Removing the Server From the Rack for
Service
To install or replace internal parts in the Sun Fire T1000 server, you must first
remove the server from the rack.
For the removal procedure, refer to the Sun Fire T1000 Server Service Manual.
Connecting the Server Cables
In order to boot the Sun Fire T1000 system, you must connect and configure the
network and serial ports. The procedures are given in the following sections.
■ “To Connect the SC Network Management Port” on page 22
■ “To Connect the SC Serial Management Port” on page 21
■ “To Connect the Ethernet Network Cables” on page 22
■ “To Connect the AC Power Cables to the Server” on page 22
FIGURE 2-9 shows the connectors on the back panel of the Sun Fire T1000 server.
