User Manual 8 Web Interface
33
devices connected to the Logger1000.
In the following, description is given by using the O&M permission as an
example.
After login for the first time, it is recommended to change the password
as soon as possible. Click "O&M user" -> "Modify password" to change
the password.
With the login password forgot en, contact SUNGROW and provide the
device S/N as well as system time, to get the password.
8.2.2 Ethernet Login
Step 1 The IP address of the PC connected to the Logger1000 is the same as that of
the Logger1000. The IP address is 12.12.12.X. For example, the IP address of
the PC can be set to 12.12.12.125, and the subnet mask is 255.255.255.0.
Step 2 Connect the Logger1000 to the PC via the Ethernet.
Step 3 Enter the IP address 12.12.12.12 of the Logger1000 in the PC address bar to
enter the general user login interface.
Step 4 Click the button "Login" in the upper right corner, enter the default password
"pw1111", and click "Login", to enter the O&M user interface.
User types include "general user" and "O&M user".
Users of different types have different permissions.
8.3 Web Main Interface
When the "O&M user" logs into the Web for the first time, the "Help" window pops
up. Follow the prompts to perform operations such as time synchronization, device
connection, and forwarding configuration.
The Web main interface is as follows:
