Sungrow 1000A - Connection to Micro-SIM; Connection to Power Box

6 Electrical Connection User Manual
26
Fig. 6-2 Connection to PV background system
Default IP of the "ETH": IP12.12.12.12.
6.5 Connection to Micro-SIM
Support of hot plug of Micro-SIM.
6.6 Connection to Power Box
The Logger1000 supports DC24V power supply. Prepare two-core DC cable,
three-core AC cable, and grounding cable before wiring. Power cable specifications
are shown in the table below.
