8 Web Interface User Manual
48
Step 1 Click "System" -> "Transfer configuration" -> "Third-party portal" to enter the
corresponding interface.
Step 2 Turn on the switch.
Step 3 Click the button on the operation bar, so that an advanced setting
window will pop up.
Step 4 Modify the configuration information and click "Save".
8.10.7 Interface
Set ports of the Logger1000 on the interface.
RS485
Step 1 Click "System" -> "Interface" -> "RS485" to enter the corresponding interface.
Step 2 Click to modify baud rate, parity bit, and stop bit.
Step 3 Click to save the information.
When the Logger1000 is connected to a device via the serial port, the
baud rate, parity bit, and stop bit of the serial port should be the same
as those set for the connected device, so as to ensure normal
communication between the Logger1000 and the connected device.
The baud rate is 9,600bps, stop bit is 1, and there is no parity bit by
default.
Ethernet
Perform Ethernet settings on this interface.
Step 1 Click "System" -> "Interface" -> "Ethernet" to enter the corresponding
interface.
Step 2 If auto IP allocation is , it is recommended to obtain the current IP
address of the ETH port by connecting the WiFi module and logging into
11.11.11.1.
Step 3 If the parameter "Automatically obtain IP settings (DHCP)" is set to ,
fill in the information such as the IP address, subnet mask, and default
gateway, and click the button
to save the operation.
The default IP address of the ETH port is 12.12.12.12.
If both auto IP allocation and WiFi STA client are enabled, ensure that the
Ethernet and the WiFi STA are at different network segment. Otherwise,
it is probably that neither of the two networks is available.
