8 Web Interface User Manual
40
Step 2 Click the button to export the device list.
Step 3 After the device list is exported, the user can modify device names in batch.
Step 4 After the modification is completed, save the device list file in the .csv format.
Step 5 Click the button to import the .csv file into the Web.
Add device
Step 1 Click "Device" -> "Device list" to enter the corresponding interface.
Step 2 Click "Add device", select a device type in the pop-up window, and fill in the
information required.
Edit device
Step 1 Click "Device" -> "Device list" to enter the corresponding interface.
Step 2 Click the button in the operation bar, to modify the name of the device
connected to the Logger1000 and other parameters.
Step 3 Click "Save".
The "Device Name" is named in the form device model (port
number-communication address).
Take SG36KTL-M (COM1-7) as an example. SG36KTL-M is device type,
COM1 is the communication port, and 7 is the communication address.
Delete device
After a device is deleted on site, the user can delete the device from the device list,
to keep device consistency.
Step 1 Click "Device" -> "Device list" to enter the corresponding interface.
Step 2 Select the device to be deleted, click the button "Delete".
Step 3 Click "Confirm" in the pop-up window, to delete the device.
8.8.2 Firmware Update
The firmware update function is used to upgrade the SUNGROW residential inverter
and string inverter.
Step 1 Click "Device" -> "Firmware update" to enter the corresponding interface.
Step 2 Click the button "Select a firmware file".Select an upgrading file and import it
to the system. Matching inverters will be detected.
Step 3 Select the device to be upgraded, and click “Upgrade”.
