7 Commissioning
7.1 Inspection before Commissioning
No.
Inspection item
Result
1
All cables are intact, well-insulated, and appropriately
dimensioned
□
2 All cables are connected correctly and firmly
□
3
The polarity of the power supply cable is correct. The grounding
cable is reliably grounded
□
7.2 Commissioning Steps
Tab. 7-1 Commissioning Steps
No. Step Result
1 Inspection before commissioning
□
2 Power on the Logger1000.
□
3 Check whether the indicators of Logger1000 normally flash.
□
4
Connect the debugging PC to the "ETH" port of the Logger1000 via
the network cable (default IP address of "ETH": 12.12.12.12).
Log in the Web at 12.12.12.12 through the IE, Safari or Chrome
browser.
□
5
Make sure the communication cable connecting the device and
the Logger1000 is firmly in place, and connect the DC circuit
breaker of the inverter to ensure the inverter is supplied with
power.
□
6
Set serial port parameters by referring to the "RS485" chapter,
including the baud rate, check bit, data bit, and stop bit.
The default setting is 9600bps, 8 data bit, 2 stop bit, and no check
bit.
□
7
Set the devices connected to the Logger1000 through the device
management function. If the device connected for the first time is
SUNGROW string inverter, use "
8.8.1 Device List" function to search
the device whose address will be automatically allocated. For
devices of other types, connect them to the Logger1000 by
referring to "8.8.1 Device List". For the devices of other types, the
□
