Sungrow 1000A - 11 Appendix; Technical Data; Quality Guarantee

68
11 Appendix
11.1 Technical Data
Communication
Max. number of devices
30 at most
Communication ports
RS485 interface
3
Ethernet
1 x RJ45, 10/100/1000Mbps
Digital input
5, Max. 24VDC
Analog input
4, support 4～20mA or 0～10VDC
Wireless Communication
4G Communication
LTE(FDD): B1, B3, B5, B8
LTE(TDD): B38,B39, B40, B41
TD-SCDMA: B34, B39
CDMA: BC0
GSM: 900/1800 MHz
WCDMA: B1, B8
WiFi communication
802.11 b/g/n/ac; HT20/40/80MHz; 2.4GHz/5GHz
Power Supply
DC input
24VDC, max. current: 1.2A
DC output
24VDC, 0.5A
Power consumption
<10W
Ambient Conditions
Operating temperature
-30℃ ~ +60℃
Storage temperature
-40℃ ~ +80℃
Relative air humidity
≤95% (no condensation)
Elevation
≤4000m
Protection class
IP20
Mechanical Parameters
Dimensions (W x H x D)
200 x 110 x 60 mm
Weight
500 g
Mounting type
Top-hat rail mounting/ wall mounting
11.2 Quality Guarantee
SUNGROW shall service or replace the faulty product for free within the warranty
