37
table 8-2 IP address of controller 2
PPoorrtt DDeeffaauulltt IIPP VViirrttuuaall IIPP
FE1 14.14.14.15
—
FE2&FE3 12.12.12.12 15.15.15.15
FE4 13.13.13.13
—
The IP address of the above port is for reference only, please refer to the
actual one!
step 3 If the parameter AAuuttoommaattiiccaallllyy oobbttaaiinn IIPP sseettttiinnggss ((DDHHCCPP)) is set to
, fill in the
information such as the IP address, subnet mask, and default gateway, and click the
button
to save the operation.
-- -- EEnndd
8.7.3 AI
step 1 Click SSyysstteemm→→PPoorrtt PPaarraammeetteerr→→AAII to enter the corresponding interface.
step 2 Select an input type, set the lower limit and upper limit, and click the button
to save
the operation.
AAII PPoorrtt
IInnppuutt TTyyppee
LLoowweerr LLiimmiitt
UUppppeerr LLiimmiitt
AI1
Voltage (V)
0 10
AI2
Current (mA)
4 20
AI3
Current (mA)
4 20
AI4
Current (mA)
4 20
-- -- EEnndd
8.7.4 DI
step 1 Click SSyysstteemm→→PPoorrtt PPaarraammeetteerr→→DDII to enter the corresponding interface.
step 2 Set the initial status to NNOO or NNCC, and click the button
to save the operation.
-- -- EEnndd
8.7.5 DO
step 1 Click SSyysstteemm→→PPoorrtt PPaarraammeetteerr→→DDOO to enter the corresponding interface.
step 2 Set the initial status of DO to NNOO or NNCC, and click
to set FFuunnccttiioonn, AAccttiioonn mmooddee,
and AAccttiioonn ttiimmee. Click
to save the settings.
-- -- EEnndd
User Manual 8 System
