Sungrow EMS300 - Port Parameter; Rs485; Ethernet

36
step 2 Click on the operation bar to export the GOOSE data configuration file to local.
step 3 Decompress the exported package, and open the .cfg file using Excel in the package.
View and modify the GOOSE data configuration file.
step 4 Save the modified GOOSE data configuration file.
step 5 Click
on the operation bar, select the modified GOOSE data configuration file, and
click OOppeenn to import it.
-- -- EEnndd
8.7 Port Parameter
Set ports of the controller on the interface. There are 7 RS485 ports (COM1~COM7).
8.7.1 RS485
step 1 Click SSyysstteemm→→PPoorrtt PPaarraammeetteerr→→RRSS448855 to enter the corresponding interface.
step 2 Click
to modify baud rate, parity bit, and stop bit.
SSeerriiaall ppoorrtt
BBaauudd rraattee
PPaarriittyy bbiitt
SSttoopp bbiitt
COM1~COM7 9600 None 1
When a serial port of controller is connected to a device, the BBaauudd RRaattee,
PPaarriittyy BBiitt, and SSttoopp BBiitt of the serial port must be configured the same as
those of the corresponding device, so as to ensure normal communication
between controller and the device.
-- -- EEnndd
8.7.2 Ethernet
Perform Ethernet settings on this interface.
step 1 Click SSyysstteemm→→PPoorrtt PPaarraammeetteerr→→EEtthheerrnneett to enter the corresponding interface.
step 2 If auto IP allocation is
, the IP address of network port in invalid. Log in to the
device using the virtual IP address.
table 8-1 IP address of controller 1
PPoorrtt DDeeffaauulltt IIPP VViirrttuuaall IIPP
FE1 14.14.14.14
—
FE2&FE3 13.13.13.13 15.15.15.15
FE4 12.12.12.12
—
8 System User Manual
