28
figure 4-6 Forklift transportation
• Move the BESS and PCS through the side fork pockets at the bottom.
• Under no circumstances should the BESS and PCS be moved by inserting the
fork feet into positions other than the fork pockets.
The fork pockets of the BESS and PCS are exposed before delivery. It is
recommended to seal the pockets with the sealing plates provided after the on-
site installation is completed.
4 Mechanical Installation System Manual
