39
figure 5-5 Copper-to-aluminum adapter terminal connection
No. Name No. Name
A
Copper bus
D
Spring washer
B
copper-toaluminum
adapter terminal
E
Flat washer
C
Bolt
F
Nut
5.3.6 Cable Entry Design
The cables connecting the outdoor cabinet and external equipment can enter the inside
from the bottom cable entry or the side cable entry of the outdoor cabinet.
System Manual 5 Electrical Connection
