Superior xp-950 - Installation Instructions; Tightening Torques for Components

63
Component Torque [Nm]
Seatpost – tightening in the frame. CAUTION: The seatpost requires only minimum tightening
to prevent it from slipping into the frame and turning. Excessive tightening may damage both
the seatpost and the frame.
5-7
- Cranks, bottom bracket assembly, pedal -
Pedal in crank 35-40
Shimano® Octalink XTR crank tightening with bolt (M15 thread) (NOT!! Hollowtech II) 40-49
Shimano® Hollowtech II bottom bracket assembly pans (2004 XTR, XT, Dura-Ace) 34-50
Shimano® Hollowtech II bottom bracket assembly pans (2004 XTR, Dura-Ace, XT) 10-15
Shimano® Hollowtech II left-hand side, adjusting bolt 0,5-0,7
Crank tightening on axle (including square axles, iISYS-type) 34-45
Encased bottom bracket assembly 40-50
- Rear derailleur, front derailleur, gear changing system -
STI shifter on handlebar 5,5-8
Rotary shifter/shifter in handlebar grip „Revo“ shifter 5,6-7,9
FD sleeve (front derailleur) 5,0-6,8
FD sleeve (front derailleur) Carbon frames 1,2-2
FD cable tightening 4,5-6,8
RD tightening on frame (rear derailleur) 8-10
RD cable tightening 3,4
RD roller tightening 3,4-4
- Brakes -
Brake jaws (road type) 7,9-10
MTB brake jaws 5,6-6,8
Brake pads – threaded 5,6-6,8
Brake pads – without thread 7,9-9
MTB brake jaws, cable tightening 5,6-7,9
Road brake jaws, cable tightening 5,6-7,9
Brake levers – MTB type 5,6-7,9
Brake levers – STI, ERGO 5,6-7,9
- Disc brakes -
Disc rotor on hub Hayes® 5,6
Hydraulic brake jaws / frame 5,6-7,9
Hydraulic hose / lever / jaws 4,5-6,8
Conversions to different units:
in-lb. = ft-lb. × 12 in-lb. = Nm × 8.851 in-lb. = kgf-cm / 1.15
