X10DRT-B+ Motherboard User’s Manual
BIOS
• 128MB SPI AMI BIOS Flash ROM
• ACPI 3.0 or later, Riser Card auto detection support,
and SMBIOS 2.7 or later,
• S4, S5
Power
• ACPI Power Management
• Power-on mode for AC power recovery
• Intel
®
Intelligent Power Node Manager (available
when the NMView utility is installed)
• Management Engine
• Riser Card auto-detection
System
Health
Monitoring
System Health Monitoring
• Onboard system health monitors for +1.8V, +3.3V,
+5V, +/-12V, +3.3V Standby,+5V Standby, +12V
Standby,VBAT, PCH, memory, PCH temperature,
system temperature, and memory temperature
• CPU 5-phase switching voltage regulator
• CPU thermal trip support
Fan Control
• Two 4-pin fan headers
• Fan speed control
LED Indicators
• CPU/system overheat LED
• Power/suspend-state indicator LED
• Fan failed LED
• UID/remote UID LED
• LAN activity LED
System
Management
• PECI (Platform Environment Conguration Interface)
2.0 support
• System resource alert via SuperDoctor® 5
• Power supply monitoring
• Redundant power supply unit detection sensor
• Thermal Monitor 2 (TM2) support
• SuperDoctor® 5, Watch Dog, NMI, RoHS
Dimensions
• 18.64" (L) x 7.20" (W) (473.46 mm x 182.88 mm)
