Chapter 2: Installation
2-17
1. IPMI_LAN
Dedicated IPMI LAN Ethernet Port
A dedicated IPMI LAN port, located next to the USB0/1 ports on the back panel, pro-
vides KVM support for IPMI 2.0 interface. This LAN port is supported by the ASpeed
AST2400 Baseboard Management Controller (BMC), and accepts an RJ45 type
cable. (Note: Please refer to the LED Indicator section for LAN LED information.)
1
IPMI CODE
BIOS
LICENSE
BAR CODE
X10DRT-B+
Rev. 1.01
1
