Supermicro X10DRT-B+ - Power & Front Control Panel Connector (JF1)

Chapter 2: Installation
2-19
Power & Front Control Panel Connector (JF1)
The JF1 add-on card connector provides front access to the power supply and the
front control panel for the X10DRT-B+ motherboard. Insert an add-on card into
this connector to use the functions indicated above. This connector is designed
specically for a Supermicro-proprietary add-on card. Refer to the layout below for
the location of JF1.
