Chapter 2: Installation
2-15
IPMI CODE
BIOS
LICENSE
BAR CODE
X10DRT-B+
Rev. 1.01
2-6 Control Panel Connectors and I/O Ports
The I/O ports are intended to be used in Supermicro Twin
2
servers. See the picture
below for the locations of I/O ports.
Back Panel Connectors and I/O Ports
Back Panel I/O Port Locations and Denitions
1. VGA port
2. USB1 (3.0)
3. USB0 (3.0)
4. Dedicated IPMI_LAN
5. UID Switch/UID LED
1
2
3
4
5
