Memory Support for E5-2600 (v3/v4)-based Motherboards
Populating RDIMM/LRDIMM DDR4 Memory Modules
Type
Ranks
Per
DIMM
and
Data
Width
DIMM Capacity
(GB)
Speed (MT/s); Voltage (V); Slots per Channel (SPC) and DIMMs per Channel (DPC)
3 Slots per Channel
1 DPC 2 DPC 3 DPC
E5-2600 V3 E5-2600 V4 E5-2600 V3 E5-2600 V4 E5-2600 V3 E5-2600 V4
4 Gb 8 Gb 1.2 V 1.2 V 1.2 V 1.2 V 1.2 V 1.2 V
RDIMM SRx4 8 GB 16 GB 2133 2400 1866 2133 1600 1600
RDIMM SRx8 4 GB 8 GB 2133 2400 1866 2133 1600 1600
RDIMM DRx8 8 GB 16 GB 2133 2400 1866 2133 1600 1600
RDIMM DRx4 16 GB 32 GB 2133 2400 1866 2133 1600 1600
LRDIMM QRx4 32 GB 64 GB 2133 2400 2133 2400 1600 1866
LRDIMM
3DS
8Rx4 64 GB
128
GB
2133 2400 2133 2400 1600 1866
