Chapter 1: Introduction
1-5
C2G41 Quick Reference
Jumpers Description Default Setting
JBT1 CMOS Clear
(See Chapter 2)
JPT1 Trusted Platform Module Enable Pins 1-2 (Enabled)
Connectors Description
JPW1 ATX 24-Pin Power Connector
COM1, COM2 COM1 and COM2 Header Connectors
DIMM 1A, 1B
Memory Slots
FAN 1-3 Fan 1: CPU Fan, Fan 2/3: Chassis Fan Headers
HDMI Back Panel HDMI Port
IDE IDE Connector
JF1 FP Control Panel Header
JL1 Chassis Intrusion Header
JWOL Wake-on-LAN Header
BUZZER Internal Buzzer/Speaker
AUDO FP Front Panel Audio Header Connector
KB/MOUSE PS/2 Keyboard/Mouse
SPDIF S/PDIF Out Header
JPW2 12V 8-Pin Power Connector
AUDIO Back Panel Audio Ports
LAN Ethernet (Gigabit LAN) Connector
LE1 Standby Power LED Indicator
I-SATA 0,1,2,3 SATA Headers
Slot 4, 5 PCI 33 MHz Slots
Slot 6 PCI-Express x1 Slot
Slot 7 PCI-Express x16 Slot
USB 0/1, 2/3 (Front Panel) USB Ports
USB 4/5, 6/7 (Back Panel) USB Ports
VGA Video/Graphics Connector
