2-28
C2G41 User's Manual
A. HD Audio
A
A
HighDenitionAudio(HDA)
The C2G41 features a 7.1+2 Channel High
Denition Audio (HDA) codec that provides
10 DAC channels, simultaneously supporting
7.1 sound playback and two channels of
independent stereo sound output (multiple
streaming) through the front panel stereo out
for front L&R, rear L&R, center and subwoofer
speakers. This feature is activated with the
Advanced software in the CD-ROM that came
with your motherboard. Sound is then output
through the Line In, Line Out and MIC jacks
(See at the picture at right).
Grey: Side
Surround
Black: Back
Surround
Orange:
CEN/LFE
Pink: Mic-In
Green:Front
Blue: Line-In
