Supero C2G41 - Front Control Panel

2-18
C2G41 User's Manual
2. Front Control Panel
JF1 contains header pins for various buttons and indicators that are normally
located on a control panel at the front of the chassis. These connectors are de-
signed specically for use with Super Micro server chassis. See Figure below for
the descriptions of the various control panel buttons and LED indicators. Refer to
the following section for descriptions and pin denitions.
JF1 Header Pins
Power Button
OH/Fan Fail LED
1
NIC1 LED
Reset Button
2
HDD LED
Power LED
Reset
PWR
LED_Anode+
LED_Anode+
LED_Anode+
LED_Anode+
Ground
Ground
X
X
X
X
FAN2
FAN1
LE1
JBT1
JF1
121
JPT1
C2G41
