PCI IDE BusMaster
Select Enabled to allow the BIOS to use the PCI busmaster to read from and write
to the onboard IDE drives. The options are Disabled and Enabled.
Slot 4 PCI 33MHz, Slot 5 PCI 33MHz, Slot 6 PCIE X1, Slot 7 PCIE X16
Select Enabled to activate the OPROM for a PCI slot specied. The options are
Enabled (to enable OPROM for the slot specied) and Disabled.
Load Onboard LAN 1 Option ROM
Select Enabled to load the onboard LAN Option ROM. The options are Enabled
and Disabled.
SuperIOConguration
Serial Port1 ~ Port2 Address
This option species the base I/O port address for the Serial Ports. Select Disabled
to prevent the serial port from accessing any system resources. When this option
is set to Disabled, the serial port physically becomes unavailable.
For Serial Port1, select the address to use as its I/O port address. The options are
Disabled, 3F8/IRQ4, 3E8/IRQ4, and 2E8/IRQ3.
For Serial Port2, select the address to use as its I/O port address. The options are
Disabled, 2F8/IRQ3, 3E8/IRQ4, and 2E8/IRQ3.
Serial Port 2 Mode
Use this feature to congure Serial Port 2 mode. The options are Normal, IrDA
and ASK IR. IrDA (Infra-Red Data) is an industry standard for remote control
devices. ASK IR (Amplitude Shifted Keying Infra-Red) is a protocol compatible
with Sharp® branded PDAs and other infra-red devices.
Hardware Health Conguration
This feature allows the user to monitor Hardware Health of the system and review
the status of each item when displayed.
CPU Overheat Alarm
This option allows the user to select the CPU Overheat Alarm setting which determines
when the CPU OH alarm will be activated to provide warning of possible CPU overheat.
Warning: Any temperature that exceeds the CPU threshold temperature
predened by the CPU manufacturer may result in CPU overheat or system
