Supero C2G41 - Back Panel Connectors - Descriptions

Chapter 2: Installation
2-17
11
Back Panel Connectors - Descriptions
Keyboard(Purple) - this port is for a keyboard with a PS/2-type con-
nector.
PS/2Mouse(Green) - attach a PS/2-type pointing device to this con-
nector, such as a mouse or a trackball.
VGA - this is the default VGA display connector.
HDMI - for High Denition monitors with an HDMI interface.
S/PDIF(Optical) - connect to receivers/speakers that has a S/PDIF-
compatible optical audio input.
S/PDIF(Coaxial) - attach to a device with a Coaxial digitial audio
input.
USB Ports - attach USB devices to these ports as needed (such
as mice, memory card readers, etc).
USB Port 5
USB Port 4
USB Port 6
USB Port 7
Gigabit LAN - connect to a network using an RJ45-type cable/connec-
tor.
SideSurround(Grey) - connect to side surround speakers/channels
(left and right).
BackSurround(Black) - connect to rear surround speakers/channels
(left and right).
CEN/LFE(Orange) - connect to the center speaker/channel and LFE
(Low Frequency Effects) speaker, usually a subwoofer.
Microphone-In(Pink)- connect to a microphone.
Front(Green)- connect to the front surround speakers/channels (left
and right).
Line-In(Blue) - attach to audio input devices such as disc players,
MP3 players, etc.
2
3
4
5
6
7
10
8
9
12
13
14
15
16
17
1
